Advanced Hybrid Magnetron Sputtering Multi-Arc Ion Plating Equipment for Superior PVD Coatings

Our state-of-the-art Magnetron Sputtering Multi-Arc Ion Plating System represents the pinnacle of Physical Vapor Deposition (PVD) technology. This innovative equipment seamlessly integrates the intense ionization of Arc Ion Plating with the stable, high-rate deposition of Magnetron Sputtering. Designed for precision and reliability, it delivers exceptionally hard, uniform, dense, and well-adhered coatings for a vast range of industrial applications.

What is Hybrid Magnetron Sputtering Multi-Arc Ion Plating Technology?

This hybrid PVD process combines two powerful techniques in a single, vacuum-based system:

  1. Multi-Arc Ion Plating (Cathodic Arc Evaporation): Utilizes high-current electric arcs to vaporize cathode material (the target). This creates a highly ionized metal plasma, resulting in coatings with excellent adhesion and density.

  2. Magnetron Sputtering: Uses a magnetically confined plasma to eject atoms from a target material. This process allows for stable, high-speed deposition of uniform coatings, even on complex geometries.

By combining these methods, our system overcomes the limitations of each individual technology. You achieve the superior adhesion and density of arc plating with the smooth, low-defect, and highly controllable deposition of magnetron sputtering.

Features

  • Enhanced Coating Quality: Produces ultra-dense, hard, and smooth coatings with superior adhesion to the substrate.

  • Excellent Uniformity: Advanced magnetic field and plasma control systems ensure consistent coating thickness across complex 3D components.

  • High Deposition Rate: Maximizes productivity and throughput with efficient material utilization.

  • Versatile Coating Capabilities: Deposit a wide array of coatings, including TiN, CrN, TiAlN, AlCrN, DLC (Diamond-Like Carbon), and multilayer nanocomposite films.

  • Superior Surface Finish: Minimizes macro-particles ("droplets"), a common challenge in standard arc processes, leading to smoother surfaces.

  • Advanced Process Control: Fully automated, PLC-controlled system with precise management of parameters like arc current, gas flow, bias voltage, and temperature.

  • Durability & Corrosion Resistance: Ideal for applications requiring extreme hardness, wear resistance, and protection against corrosion and oxidation.

Technical Specifications

Parameter Specification
Process Technology Combined Magnetron Sputtering & Multi-Arc Ion Plating
Vacuum Chamber Custom sizes available; Stainless Steel construction
Vacuum System High-capacity diffusion pump/turbo molecular pump system
Arc Sources Multiple, electromagnetically controlled cathodic arc sources
Magnetron Sputtering Balanced or Unbalanced magnetrons with DC/RF/Pulsed DC power
Substrate Bias DC Pulse Bias or RF Bias for enhanced ion bombardment
Heating System Radiant heaters with precise temperature control (up to 600°C+)
Gas Control Mass Flow Controllers for Ar, N₂, C₂H₂, O₂, etc.
Control System Fully automated PLC with HMI (Human-Machine Interface)

Applications

Our Magnetron Sputtering Multi-Arc Ion Plating System is essential for industries that demand high-performance surface engineering:

  • Cutting & Forming Tools: Drills, end mills, inserts, punches, and dies (coated with TiN, TiAlN, AlCrN) for dramatically extended tool life.

  • Aerospace & Automotive Components: Coatings for engine parts, transmission components, and landing gear to enhance wear and corrosion resistance.

  • Decorative Coatings: Provides durable, scratch-resistant, and brilliant finishes (e.g., gold, rose gold, black) for watches, jewelry, and consumer electronics.

  • Medical Devices: Biocompatible coatings on surgical instruments, implants, and orthopedic devices for improved performance and longevity.

  • Precision Machinery Parts: Gears, bearings, and molds to reduce friction and increase service life.

Why Choose Hongfeng VAC's PVD System?

We are a leading manufacturer of advanced surface coating solutions. Our Magnetron Multi-Arc Composite Ion Plating Equipment is engineered for:

  • Reliability: Built with robust components for continuous industrial operation.

  • Flexibility: Configurable to meet specific R&D or high-volume production needs.

  • Expert Support: Comprehensive technical support, training, and service from our team of engineers.
