AR Glass Sputtering Coating System
for high-performance anti-reflective glass manufacturing
Our advanced AR Glass Sputtering Equipment delivers precise, uniform thin-film deposition for anti-reflective glass used in displays, solar panels, architectural glazing, and optical components. Designed for industrial-scale production, it ensures high throughput, excellent layer adhesion, and superior optical performance.
Features
✔ High-uniformity Magnetron Sputtering – Achieve ±1% thickness uniformity across large glass panels (up to 2.5×3.0 m).
✔ Multi-layer Coating Capability – Deposit single or multi-layer AR stacks (e.g., SiO₂/Nb₂O₅/SiO₂) with tight process control.
✔ In-line or Batch Configurations – Flexible system design to match your production volume and floor space.
✔ Closed-loop Plasma Monitoring – Real-time feedback ensures stable refractive index and extinction coefficient.
✔ Low Particle & Defect Density – Class 10 cleanroom-compatible design for high-yield optical coating.
✔ Energy-efficient Power Supplies – Pulsed DC & MF generators lower operating costs.
✔ User-friendly HMI + Recipe Management – One-touch recall for different AR specifications (single-side, double-side, broadband AR).
🔹 Technical Specifications
| Parameter | Value / Range |
|---|---|
| Substrate size (max) | Customizable |
| Coating materials | SiO₂, TiO₂, Nb₂O₅, Si₃N₄, ITO, etc. |
| Number of cathodes | 6–20 (rotatable or planar) |
| Base pressure | ≤ 5×10⁻⁵ Pa |
| Deposition uniformity | ≤ ±1% (sheet resistance / thickness) |
| Throughput | Up to 200 panes/hour (depending on layer count) |
| Optical monitoring | In-situ transmission/reflection |
| Power supply | 10–120 kW pulsed DC / MF / RF |
🔹 Applications
Display cover glass (smartphones, tablets, TVs)
Solar PV glass – reduces reflection, boosts transmittance ≥ 96%
Architectural & automotive glazing – anti-glare, energy-saving
High-end optical lenses & filters
🔹 Why Choose Our AR Sputtering System?
Proven stability – 24/7 continuous operation with minimal drift.
Fast target changeover – patented target clamp design reduces downtime.
Pre-coated glass examples – We provide test runs with your substrate to demonstrate performance.
Global support – On-site installation, training, and remote diagnostics.
🔹 Get a Quote
Ready to improve your AR glass production? Contact our team for a customized solution – including vacuum, gas, cooling, and automation options.
