KYKY CXF-320/3001 Magnetic Suspension Molecular Pump
KYKY Turbo Molecular Pump Features
Energy saving: frictionless, avoiding frictional heat loss, reducing energy consumption by 30% compared to other types of products
Efficiency: longer continuous working time, high air flow rate, and high pumping speed
Flexible: Compact structure, meets smaller physical space requirements, can be installed at any angle, suitable for various design needs, rich expansion functions, and meets customer customization needs
Applications:
Scientific research
Accelerator
Photovoltaic
Low-E glass coating
ITO coating
Optical coating
Decorative coating
Tablet display
Vacuum furnace
Electric vacuum
New energy
New materials
Vacuum drying
Low temperature refrigeration
Thin film deposition
Etching
Ion implantation
Photolithography
Electronic device
Technical Specifications:
| Brand | KYKY |
| Model Number | CXF-320/3001 |
| Inlet Flange | DN320 ISO F(standard configuration) |
| Pumping Rate | N2:2950 Ar:2750 He:2300 H2:1100 |
| Ultimate Vacuum Pressure | 1E-7Pa |
| Protective gas inlet flange (optional) | KF10 |
| Maximum allowable magnetic field strength | Radial: 3 Axial: 15 |
| Downtime | ≤12min |
| Cooling water flow volume | 3 L/min |
| Power source voltage(V/AC) | 220±10％，50Hz 110±10％，60Hz |
| Exhaust outlet flange | KF40 |
| Compression ratio | N2:＞1E8 Ar:＞1E8 He:＞1E4 H2:＞1E3 |
| Start time | ≤9min |
| Cooling way | Water cooling |
| Cooling water temperature | 20±5 °C |
| Controller model | CXFD-1601 |
| Weight | ISO F 76KG |
Dimensions:
