KYKY Ultra High Vacuum Electric Gate Valve For Vacuum System
CCD type ultra-high vacuum electric gate valve is a newly developed ultra-thin valve. It is powered by a stepper motor and uses a threaded screw transmission mechanism to push (pull) the valve core component for linear motion, thereby controlling the opening or closing of the valve. Its opening or closing position can be adjusted arbitrarily. This series of plug-in valves is suitable for applications where the working medium is air and non corrosive gases. It is equipped with a PNP photoelectric switch to control the opening and closing position of the valve.
CCD type ultra-high vacuum electric gate valve model:
CCD-35B、CCD-50B、CCD-63B、CCD-80A、CCD-100A、CCD-150A、CCD-200A、CCD-250A、CCD-320B、CCD-400B。
Valve standard interface form:
Standard Flange:
CF、ISO-F
The working principle of the electric high vacuum gate valve is to drive the valve plate to move linearly in the valve body through an electric device (such as a motor), so as to control the opening and closing of the valve. When the valve plate is fully opened, the air flow can smoothly pass through the valve; and when the valve plate is fully closed, the valve can effectively block the air flow to ensure the stability and reliability of the vacuum system.
1 Structure
Electric high vacuum gate valve is mainly composed of valve body, valve plate, electric device, sealing device and transmission mechanism.
The valve body is usually made of high-strength and corrosion-resistant materials such as stainless steel to ensure the durability and airtightness of the valve.
Valve plate is the key component of the valve, and its material and shape design should meet the requirements of high vacuum environment.
The electric device is used to provide driving force to control the moving speed and position of the valve plate.
The sealing device usually adopts metal sealing or soft sealing structure to ensure the airtightness of the valve in the closed state.
2 Features
Electric high vacuum gate valve has the characteristics of good sealing performance and low leakage rate, which can meet the requirements of high vacuum system.
The valve is compact in structure, small in size, and easy to install and maintain.
The electric device is easy to operate, flexible and reliable, and can realize remote control and automatic control.
The valve has a long service life and can withstand a certain pressure and temperature range.
3 Application
Electric high vacuum gate valve is widely used in the field of high vacuum environment, such as semiconductor manufacturing, material science research, aerospace technology, medical equipment manufacturing and scientific research experiments. In these fields, the electric high vacuum gate valve can effectively control the air flow and pressure of the vacuum system, and ensure the stability and reliability of the experiment or production process.
