Plasma Immersion Ion Implantation and Deposition System



General Information

Plasma Immersion Ion Implantation and Deposition (PIIID) System represents a revolutionary advancement in surface modification technology. Unlike conventional beam-line ion implanters that require line-of-sight processing, the PIIID system immerses the workpiece entirely in a low-pressure, high-density uniform plasma. By applying a high-voltage negative pulsed bias to the workpiece, ions are accelerated and implanted uniformly from all directions simultaneously.

This unique approach eliminates the directional limitations of traditional ion implantation and thin-film deposition methods, delivering exceptional results on complex three-dimensional geometries. Whether you are processing aerospace components, precision bearings, semiconductor devices, or cutting tools, the PIIID system offers unparalleled surface engineering capabilities.

Hongfeng VAC — a professional manufacturer of high-tech PVD coating equipment based in Xiangtan, Hunan, China — brings years of expertise in vacuum system design and manufacturing to deliver this advanced PIIID solution. Every system is engineered with an unwavering commitment to quality, backed by a dedicated team of technical experts.

For Plasma Immersion Ion Implantation and Deposition System, it is mainly composed of double-wall process chamber, vacuum pumping system, 2 sets of filtered vacuum cathodic arc FCVA sources, 2 sets of Kaufman Ion Source KIS, RF-CCP plasma source, High Voltage Pulse Modulator HVPM, high voltage workpiece holder, gas line system, chamber temperature control, manual operating system and so on. 2 sets of FCVA sources can be used to generate metallic ions for either metal film or reactive deposition. The FCVA sources are able to do surface treatment with processing height >200mm. 2 sets of KIS sources can be used to do surface cleaning and sputtering with argon gas and the
cleaning height is >200mm RF-CCP plasma source can be used to generate gaseous plasma for either reactive deposition, plasma etching or plasma immersion ion implantation with HVPM.


1. Features

  •  Stainless Steel double wall chamber with water cooling
  •  Temperature control up to 350℃
  •  High voltage workpiece holder with water tower cooling and rotation
  •  Filtered cathodic vacuum arc sources with full metallic plasma output
  •  Kaufman ion sources for sample cleaning
  •  RF-CCP source for gaseous plasma generation
  •  High voltage pulse modulator for sample bias


2. Main Specifications

  •  Stainless Steel chamber with double wall cooling: Φ650XH720mm
  •  KYKY turbopump (2000 L/s) and 18 L/s mechanical pump for pumping system, base pressure≤ 5X10-4 Pa, the rate of rise in pressure: ≤ 0.5Pa/h, adjustable pumping rate by throttle valve
  •  High voltage workpiece holder: special designed for plasma immersion ion implantation process with rotation and quartz glass shielding to avoid contamination
  • Temperature control system: 6 surrounding heater bars with power up to 5 kW, PID auto control chamber temperature up to 350°C
  • Gas feeding system: 5 mass flow controllers with isolated valves, separately feed into arc sources ion sources and main chamber
  • 2 sets of filtered cathodic vacuum arc sources
  • 2 sets of Kaufman ion sources
  • 1 set of RF-CCP plasma source with maximum output power of 1kW, 13.56MHz
  • 2 sets of shutter valves for FCVA sources
  • 2 sets of shutter valves for Kaufman ion sources
  • 1 viewport with Lead glass and shutter

3. Applications:

  • The PIIID system delivers exceptional value across multiple industries:
  • Semiconductor & Electronics — Conformal doping of non-planar device structures, ultra-shallow junction formation, trench isolation structures, and silicon-on-insulator fabrication.
  • Aerospace & Defense — Surface strengthening and wear protection of critical components with complex geometries.
  • Precision Manufacturing — Surface modification of bearings (GCr15, 2Cr13), industrial components with irregular shapes, and batch treatment applications.
  • Tooling & Molds — Deposition of diamond-like carbon (DLC) and nano-diamond films for enhanced wear resistance and reduced friction.
  • Automotive — Tribological coatings and surface engineering of powertrain components.
  • Medical Devices — Biocompatible surface modifications for implants and surgical instruments.

Why Hongfeng VAC?

Custom Manufacturing Expertise — Specializing in non-standard vacuum coating systems designed to meet specific customer requirements
Proven Track Record — Established in 2008 with years of experience in vacuum equipment manufacturing
Comprehensive Support — 1-year warranty, free replacement parts, online technical support, and mechanical test reports available
Global Reach — Export-standard packaging with OEM/ODM services accepted
Quality Commitment — Every system undergoes rigorous testing before delivery

Ready to elevate your surface engineering capabilities? Contact Hongfeng VAC today to discuss your specific requirements.
